Product Specifications
MPN: | 519-KCA2322X |
UPC: | 803467026534 |
Included Hardware: | YES |
Inner Diameter: | Inboard: 2 1/2 (2.504 Inches); Outboard: 2 13/16 (2.831 Inches) |
Material: | 40Cr Steel |
Axle Length: | 19 1/16 (19.075 Inches) |
Boot Material: | Neoprene Polychloroprene (CR) |
Inboard Spline Diameter: | 2 1/2 (2.504 Inches) |
Inboard Splines: | 20 Teeth |
Outboard Spline Diameter: | 2 13/16 (2.831 Inches) |
Outboard Splines: | 21 Teeth |
Shaft Diameter: | 3/4 (0.748 Inches) |
Shaft Material: | 40Cr Steel |
Thread Measurement: | M16X1.5 |
